D79-140QL Hub Motor Unit (eCargo + eFat)
36V NAKED PACK DIMENSIONS
All sizes below include holders, insulation, heat-shrink, wiring, and side-mounted high-current BMS allowance.
| Config | Capacity (Ah) | Cell Count | Dimensions (L × W × H, in) | Dimensions (mm) | Max Continuous (A) | Notes |
|---|---|---|---|---|---|---|
| 10S3P | 15Ah | 30 | 8.9 × 2.8 × 3.3 | 226 × 71 × 85 | 100A | Compact commuter |
| 10S4P | 20Ah | 40 | 8.9 × 3.7 × 3.3 | 226 × 94 × 85 | 120A | Good range upgrade |
| 10S5P | 25Ah | 50 | 8.9 × 4.6 × 3.3 | 226 × 117 × 85 | 150A | Mid-capacity |
| 10S6P | 30Ah | 60 | 8.9 × 5.5 × 3.3 | 226 × 140 × 85 | 180A | Balanced build |
| 10S7P | 35Ah | 70 | 8.9 × 6.4 × 3.3 | 226 × 163 × 85 | 200A | High power |
| 10S8P | 40Ah | 80 | 8.9 × 7.3 × 3.3 | 226 × 186 × 85 | 220A | Fleet / commuter |
| 10S9P | 45Ah | 90 | 8.9 × 8.2 × 3.3 | 226 × 209 × 85 | 250A | Heavy duty |
| 10S10P | 50Ah | 100 | 8.9 × 9.1 × 3.3 | 226 × 232 × 85 | 300A | Max 36V build |
- Free worldwide shipping
- Low stock - 3 items left
- Backordered, shipping soon
Description
DUAL Hub Motor System
2 x 1500 Watt Motors 60V ( 3000 Watt)
WHY CHOOSE THE D79-140QL ELECTRIC BIKE HUB MOTOR?
Exceptional Design: D79-140QL electric bike Hub Motor Crafted for fat tire e-bikes, ensuring an unmatched riding experience.
Customizable Power: Ranging from a minimum of 1000W, up to a thrilling 2000W, all with a max torque of 110N.m!
Built to Last: Robust aluminum alloys resist rust, corrosion, dust, and humidity.
Lightweight & Durable: Perfect balance of durability and featherweight design.
Whisper-Quiet: Integrated high-power motor for silent efficiency and rapid response.
High Efficiency, Low Noise: Enjoy high efficiency, minimal noise, and rapid responsiveness.
Contact Us Now To Elevate Your E-Bike Adventure!
Introducing the FTB Dual Drive Motor - Power, Precision, and Performance Redefined!
The FTB Dual Drive Motor is engineered to deliver unparalleled power and precision, setting a new standard in electric propulsion technology. Designed for 20-inch wheel applications, this motor boasts a remarkable 60V 3000W output, providing the raw energy needed to propel your ride to new heights.
Featuring a dual-drive configuration with D79 motors installed at both the front and rear, each boasting an impressive 1500W output, this motor system offers symmetrical power distribution for exceptional balance and control. Whether you're cruising through urban streets or tackling rugged terrain, the FTB Dual Drive Motor ensures smooth acceleration and effortless maneuverability in any environment.
Built to withstand the demands of high-performance riding, this motor is constructed with durability in mind. From its rugged exterior casing to its precision-engineered internal components, every aspect of the FTB Dual Drive Motor is designed to withstand the rigors of intense use, ensuring reliability and longevity for years to come.
But power is just one part of the equation – the FTB Dual Drive Motor also offers precision handling and control, thanks to its advanced design and engineering. With smooth acceleration and responsive throttle control, you'll experience a seamless riding experience that puts you in command of the road ahead.
Whether you're a seasoned rider looking to take your electric bike to the next level or a newcomer seeking the ultimate in performance and versatility, the FTB Dual Drive Motor is the perfect choice. Experience the thrill of unmatched power, precision, and performance with the FTB Dual Drive Motor – your gateway to a new era of electric mobility.
Key Features:
- Dual-drive configuration with D79 motors at the front and rear (each 1500W)
- 20-inch wheel compatibility
- 60V 3000W output for exceptional power
- Rugged construction for durability and longevity
- Smooth acceleration and responsive throttle control for precision handling
- Perfect for urban commuting, off-road adventures, and everything in between
Take your electric ride to the next level with the FTB Dual Drive Motor – the ultimate expression of power, precision, and performance.
Information
ADDITIONAL INFORMATION
| D79 Series |
D79-140QL |
|---|---|
| Color |
Black / Silver |
| Installation Site |
Front & Rear |
| Applied for E-bikes |
e-FAT |
| Cable Routing |
Side-Left |
| Cable Length(mm) |
200 |
| Sprocket Wheel |
N.A. |
| Brake Style |
Disk-Brake |
| Spokes Holes |
36H |
| Spokes Size |
13G/12G |
| Spokes Central Dist.(mm) |
174 |
| Open Size(mm) |
140 |
| Wheel Size(inch) |
20/26/28/700C |
| Voltage(Vdc) |
48, 52, 60 |
| Rated Power(W) |
1000,1500,2000 |
| Max Speed(km/h) |
50, 55, 60 |
| Max Torque(N.m) |
110 |
| Reduction Ratio |
5.8:1 |
| Magnet Items(pcs) |
16 |
| Speed Sensor(pcs) |
1～6 |
| Efficiency(%) |
≥80 |
| Work Temperature(℃) |
-20～45 |
| Noise Items(dB) |
＜50 |
| Weight(kg) |
5.5 |
| Waterproof Level |
IP65 |
| Shells Material |
Aluminium Alloy |
