Frame material Seamless iron alloy frame
Front Tyre size 100/406-20
Rear Tyre size 225/40-10
Tyre pressure front 200kpa, rear 250kpa
Front fork ronzlla mechanical Fork
Derailleur Shift System NO
Brake type Front and Rear Disc brake
Motor power 60V, 3000W brushless motor
Max speed 45km/h for Europe, 65km/h for USA
Grade-ability 30 degrees
Max loading 200 kg
Battery 60V, 25Ah Lithium-ion removable battery
Range 50-75 km
Charger MGSD 67.2V, 5A
Charging time 4-5 hours
Working temperature -20~40℃
Waterproof standard IP54
Display LCD display
Front Shock Absorber Hydraulic shock Fork
Rear Shock Absorber Aluminum alloy spring shock absorber
Light system LED headlight, brake light, turn lights, side reflector,
Suitable height 160-210 cm
Alarm alarm with 2 pieces remote
Product net weight 81 kg
Gross weight 92 kg
Certificates CE, FCC, ROHS, EEC, COC, CNIT, UTAC, DOT, MSDS, UN38.3
Product size 210*91*130 cm （L*W*H)
Package size 188*37.5*77 cm（L*W*H)
Package list golf scooter m6g, mirrors, charger, tools, user manual
Golf Scooter Rooder Mangosteen M6g Electronics:
Battery 60V/25AH removable lithium battery, 1500WH (60v*25=1500wh), 505km range depends on the road condition, driver's weight, speed and so on.
Charger 67.2V~5A MGSD quick charger, fully charged with 5-6 hours. (25ah/5a=5h)
Controller 60V/55A Integrated controller which supports 65kmph+ speed
Display Motor-style LCD
with charge indicator, speedometer,
odometer, trip odometer, throttle gear level, and so on.
Motor 3000W Brushless DC Geared Motor with 186 NM max torque, up to 65km/h (max speed). Motor brand: QS motor or YUMA motor.
Lights Front: Oversized headlight with turn light
Rear: Integrated taillight on the fender with brake light, and direction indicator.
Throttle Three levels of gear throttle in the default. 45kmph max for European market and 40mph(65kmph) for US market. Speed can switch betwen 45/65kmph by changing the speed limit setting.
Kickstand Electric cut off when getting on the kickstand
Electric Golf Scooter Rooder Mangosteen M6g Components:
Tires front 20" and rear 10″ straight grain vacuum tubeless tires
Fenders Made of ABS material by MGSD.
Brakes Front and Rear Hydraulic disc brakes
Frame Seamless iron alloy frame
Front Suspension Hydraulic shock Fork
Rear Suspension Spring steel shock
Seat double seat in leather
Rooder Mangosteen Golf Citycoco M6g Geometry:
Seat Height 63.5cm
Handlebar Height 77cm
Total Length 212cm
Handlebar Width 85cm
Rear Suspension Length 24.38cm
Footrest Size 12.44cm * 14.47cm
Kickstand Length 17cm
Controller Size 17.2cm* 9.4cm
Front Brake Hose 1100mm
Rear Brake Hose 2250mm
Rear Registration Plate Size 14.45cm * 12.5cm
Hydraulic Reservoir 24ml
Tire Pressure Front: 200 kPa, Rear: 250 kPa
Net Weight 76kg
Gross Weight 100kg
Recommend Rider Height Over 140cm
Battery Charging process & Tips
The RPE battery can be also charged through the Anderson connectors for high current charge but for the standard low current options please use the barrel connector. The RPE Charger Scheme should match these colors, do not mix match the color as it could cause harm to the battery. It is recommend that you use the EMP Low current charger; if not do not exceed 7 amps of charger current or you will risk damaging the barrel connectors charging wire. Never leave a battery charging unattended.
This chart will explain the ranges of your Naked RPE battery to expect from the battery cells anything lower or higher than these is a good indication that your battery is potentially damaged
IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS BATTERIES
EMP Drop Test on our batteries!!
IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS For LI-ION/POLYMER BATTERIES
General Guidelines and Warnings
Storage & Transportation
Charging and Typical maintenance
Ebikes & Bafang Motor Warranty
Bikes are warrantied through the original OEM.
Energie Cycles are warrantied through Ebikemarketplace.com.
Bafang motors are covered under a limited warranty through Bafang NA.
Warranties are for the original buyer and do not extend to secondary sales.
Ebikemarketplace.com will replace a Bafang motor up to one (1) time then it is up to the buyer to maintain the integrity of the motor and forward all continuing issues to Bafang NA per the Bafang warranty.
